Touchscreen LCD Monitor
Fitur Utama :
- Choice of Sizes with Full HD Quality
- SHARP Touch Viewing Software
- Simultaneous Writing
- User-Friendly SHARP Pen Software
- MFP Connectivity
- Handwriting Recognition
- SHARP Display Connect
| Specification (IW) (-) | |
| MODEL | Touchscreen LCD Monitor |
| Installation | Landscape |
| LCD Panel | 70-inch-class (69 1/2-inch [176.6 cm] diagonal) UV2A LCD |
| Max. Display Colours (approx.) | 1.07 billion colours |
| Pixel Pitch | 0.802 x 0.802 mm |
| Brightness | 350 cd/m2 |
| Contrast Ratio | 4,000 : 1 |
| Viewing Angles (H/V) | 176 deg /176 deg (CR 10) |
| Active Screen Area (W x H) | 1,538.9 x 865.6 mm (60 9/16" x 34 1/16") |
| Response Time | 8 ms (grey to grey, avg.) |
| Backlight | LED, edge lit |
| Touch Technology1 | IR (infrared blocking detection method) |
| Multi Touch | 10 points |
| Protection Glass | Thickness: approx. 3.1 mm Shock resistance: 130 cm |
| VIDEO | Analogue RGB (0.7 Vp-p) [75ohm] |
| Max. Resolution | 1,920 x 1,080 pixels |
| Synchronisation | Horizontal/vertical separation (TTL: positive/negative) |
| Plug & Play | VESA DDC2B |
| Power Management | - |
| Input Terminals | - |
| Output Terminals | 3.5 mm-diameter mini stereo jack x 1 |
| Input/Output Terminals | - |
| USB Hub Function | - |
| Expansion Slot | 12 V, 2.4 A (power supplied when expanding the functions with an optional part) |
| Speaker Output | 10 W + 10 W |
| Mounting | VESA (4 points), 400 x 400 mm, M6 screw |
| Power Supply | 100 V - 240 V AC, 50/60 Hz |
| Power Consumption | 200 W |
| Operating Temperature | 5 degree Celcius to 35 degree Celcius |
| Operating Humidity | 20% to 80% RH (no condensation) |
| Dimensions (W x D x H) (approx.) (display only) | 1,635 x 96 x 998 mm (64 3/8" x 3 3/4" x 39 5/16") |
| Weight (approx.) | 62 kg (136.7 lbs) |
| Main Accessories | - |
