Touchscreen LCD Monitor
PN-70SC5 Compare

Fitur Utama :

  • Choice of Sizes with Full HD Quality
  • SHARP Touch Viewing Software
  • Simultaneous Writing
  • User-Friendly SHARP Pen Software
  • MFP Connectivity
  • Handwriting Recognition
  • SHARP Display Connect
WHERE TO BUY
Specification (IW) (-)
MODEL Touchscreen LCD Monitor
Installation Landscape
LCD Panel 70-inch-class (69 1/2-inch [176.6 cm] diagonal) UV2A LCD
Max. Display Colours (approx.) 1.07 billion colours
Pixel Pitch 0.802 x 0.802 mm
Brightness 350 cd/m2
Contrast Ratio 4,000 : 1
Viewing Angles (H/V) 176 deg /176 deg (CR 10)
Active Screen Area (W x H) 1,538.9 x 865.6 mm (60 9/16" x 34 1/16")
Response Time 8 ms (grey to grey, avg.)
Backlight LED, edge lit
Touch Technology1 IR (infrared blocking detection method)
Multi Touch 10 points
Protection Glass Thickness: approx. 3.1 mm Shock resistance: 130 cm
VIDEO Analogue RGB (0.7 Vp-p) [75ohm]
Max. Resolution 1,920 x 1,080 pixels
Synchronisation Horizontal/vertical separation (TTL: positive/negative)
Plug & Play VESA DDC2B
Power Management -
Input Terminals -
Output Terminals 3.5 mm-diameter mini stereo jack x 1
Input/Output Terminals -
USB Hub Function -
Expansion Slot 12 V, 2.4 A (power supplied when expanding the functions with an optional part)
Speaker Output 10 W + 10 W
Mounting VESA (4 points), 400 x 400 mm, M6 screw
Power Supply 100 V - 240 V AC, 50/60 Hz
Power Consumption 200 W
Operating Temperature 5 degree Celcius to 35 degree Celcius
Operating Humidity 20% to 80% RH (no condensation)
Dimensions (W x D x H) (approx.) (display only) 1,635 x 96 x 998 mm (64 3/8" x 3 3/4" x 39 5/16")
Weight (approx.) 62 kg (136.7 lbs)
Main Accessories -
